SP-3016HSS - High Speed Bridge Type Machining Center

Location:Boca Raton, FL

or
Call 513-382-1736

Description

Show All

Specifications

ManufacturerYama Seiki
ModelSP-3016HSS
ConditionNew
Spindle nose to table top6.3" ~ 36.2"
Distance between columns51.2" | 66.9" | 66.9" | 66.9"
Table size ( X / Y )128.3" / 59.0"
Table load capacity22,000 lb
Spindle motor30 HP ( 30 min. )
Spindle speed10 ~ 15,000 rpm | 10 ~ 15,000 rpm | 10 ~ 15,000 rpm | 10 ~ 6,000 rpm( Standard ), 10 ~ 8,000 rpmdirect driven( Option )
Print This PageVP-2012HSS | SP-2016HSS | SP-3016HSS | SP-3016
X travel78.7" | 82.7" | 120.5" | 120.5"
Y travel47.2" | 63.0" | 63.0" | 63.0"
Z travel30.0" | 30.0" | 30.0" | 30.0"
Table size78.7" x 43.3" | 90.9" x 59.0" | 128.3" x 59.0" | 128.3" x 59.0"
Max. table load7,700 lb | 17,600 lb | 22,000 lb | 22,000 lb
Spindle motor ( cont. / 30min. )25 / 30 HP | 25 / 30 HP | 25 / 30 HP | 30 / 35 HP
Spindle taperCAT40 | CAT40 | CAT40 | CAT50
Distance nose to table6.3" ~ 36.2" | 6.3" ~ 36.2" | 6.3" ~ 36.2" | 9.4" ~ 39.4"
Rapid traverse ( X,Y axes )787.4 IPM. | 787.4 IPM. | 787.4 IPM. | 787.4 IPM.
Z axis590.5 IPM. | 590.5 IPM. | 590.5 IPM. | 393.7 IPM.
Cutting feedrate0.04 ~ 393.7 IPM. | 0.04 ~ 393.7 IPM. | 0.04 ~ 393.7IPM. | 0.04 ~ 393.7 IPM.
Repeatability± 0.0001" | ± 0.0001" | ± 0.0001" | ± 0.0001"
Positioning accuracy± 0.0002" Full travel | ± 0.0004" Full travel | ± 0.0004"Full travel | ± 0.0006" Full travel
Tool capacity32 | 32 | 32 | 32 ( 60, 90, 120 Option )
Tool holder spec.CAT40 | CAT50 | CAT50 | CAT50
Max. tool DIA. / adjacent empty4" / ------ | 4" / 5" | 4" / 5" | 5.0" / 8.5"
Max. tool length11.8" | 11.8" | 11.8" | 13.8"
Max. tool weight15 lb | 15 lb | 15 lb | 44 lb
Tool changing time ( tool to tool )12 sec. | 12 sec. | 12 sec. | 8 sec.
Length228" | 264" | 342" | 342"
Width194" | 184" | 184" | 185"
Height141" | 153" | 153" | 157"
